- Simple installation, set-up and maintenance
- Resistant to contamination, operational with optics 90% contaminated
- Lower levels of maintenance than traditional opacity systems
- Can be purged with instrument air providing lower cost of ownership; blowers available if preferred
- Used for compliance measurement (mg/m3) after electrostatic precipitators and baghouses
- Advanced sensor design includes automatic drift (zero and span) checks
- mg/m3 output, once calibrated.
- Stacks after bag filters, cartridge filters, cyclones, electrostatic precipitators, no filtration
- Non-condensing / dry flue gases
- Typical Applications:
- Incineration
- Metals (eg Steel/Aluminium)
- Minerals (eg Cement/Gypsum)
- Chemicals (eg Refinery / Rubber)
- Power Generation Plant (eg Coal/Biomass)
| Technical Specifications | |
|---|---|
| Measured parameters | Dust |
| Technology | DynamicOpacity™ |
| Measurement/Monitoring capability | <10 – 1000 mg/m3* |
| Stack/Duct diameter suitability | up to 15m |
| Flue gas temperature | up to 600°C |
| Baghouse | YES |
| Cartridge Filter | / |
| Ceramic Filter | / |
| Coalescent Filter | / |
| Cyclone | YES |
| Electrostatic Precipitator (ESP) | YES |
| Wet Electrostatic Precipitator (WESP) | / |
| Wet Scrubber | / |
| Sensor variants | Stainless Steel |
| QA checks | YES |
*Application dependant
| Technical data | |
|---|---|
| Measurement capability | <10 – 1000 mg/m3 |
| Sensor Variants | 316 Stainless Steel (head and coupling) |
| Stack Temperature Ranges | -25°C -250°C (standard) up to 600°C (option) |
| Functionality and QA Checks | Automatic zero, span and light checks |
| Interface | Available with standard control unit (Interface module) for single stack or with ProController for multi-sensor networks |
| On-board data logging | User configurable, Long term, Short term or Pulse logging |
| Output | RS232, RS485 (Modbus), Ethernet Digital Alarm and 4/20mA (number of outputs dependant on controller type) |
| Air Purge | instrument air or blower |
| Enclosure Protection Rating | IP65 |
- TÜV approved
